1.5 Inch 2 Way NC Electric Plastic Water Solenoid Valve 12VDC 24VDC 110VAC 220VAC

1.5 Inch 2 Way NC Electric Plastic Water Solenoid Valve 12VDC 24VDC 110VAC 220VAC

  • 1.5 Inch 2 Way NC Electric Plastic Water Solenoid Valve 12VDC 24VDC 110VAC 220VAC
1.5 Inch 2 Way NC Electric Plastic Water Solenoid Valve 12VDC 24VDC 110VAC 220VAC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 2W400-40
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Function: 2 Way, Normally Closed Action: Direct Lifting Diaphragm
Product Name: ABS Plastic Solenoid Valve Working Fluids: Air, Liquids, Water, Gas
Port Size (inch): 1/4'' To 2'' Orifice Size: 2.5mm To 25mm
Voltages: 24VAC, 110VAC, 220VAC (50/60Hz), 12VDC, 24VDC Seal Material: NBR
Pressure Range: 0 To 10 Bar Thread Type: Threaded (G, NPT)
High Light:

1 1/2 Inch Plastic Solenoid Valve

,

Direct Lifting Solenoid Valve

,

Normally Closed Solenoid Valve

1.5 Inch 2 Way NC Electric Plastic Water Solenoid Valve 12VDC 24VDC 110VAC 220VAC



Product Features:

1. Port Size: 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''; Thread Port (G, NPT).

2. Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm.

3. Function: 2 Way, Normally Closed.

4. Body Material: ABS

5. Seal Material: NBR

6. Working Medium: Water, Liquid, Gas, Air

7. Fluid Temperatrue: -5 to +80℃

8. Voltages: 110VAC, 220VAC, 12VDC, 24VDC, other voltages can be customized.



This plastic solenoid valve is a two-way, normally closed, semi-direct acting solenoid valve that can work without minimum pressure difference. When the coil is de-energized, the plunger and flexible diaphragm are located on the main valve hole. The working medium flows through a tiny "discharge hole" and pressurizes the cavity above the diaphragm-the system pressure and spring force seal the valve. When the valve is energized, the diaphragm is pulled away from the main orifice, allowing fluid to flow through the valve. Since the size of the discharge hole is smaller than the size of the main hole, the system pressure cannot be rebuilt on the top of the diaphragm as long as the main hole remains open.



Main Dimension of 1-1/2 Inch Plastic Solenoid Valve:

1.5 Inch 2 Way NC Electric Plastic Water Solenoid Valve 12VDC 24VDC 110VAC 220VAC 0

2W Series
B (Width)
C (Length)
D (Height)
E
2W160-15
61
115
69
G1/2''
2W200-20
61
120
80
G3/4''
2W250-25
80
130
99
G1''
2W350-35
80
136
117
G1-1/4''
2W400-40
104
174
120
G1-1/2''
2W500-50
105
185
150
G2''



Technical Data of Plastic Solenoid Valve:

2W Series
2W025-08
2W040-10
2W160-15
2W200-20
2W250-25
2W350-35
2W400-40
2W500-50
Orifice Size
2.5
4
15
20
25
35
40
50
Port Size
1/4''
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''
2''
Medium
Water, Air, Liquid, Gas
Action
Direct Acting
Semi-Direct
Function
2 Way, Normally Closed
Fluid Viscosity
20 CST below
Pressure
Range
0 to 1.0 Mpa
Temp. Range
-5 to +80℃
