Name: DB112/G Diaphragm Repair Kit For 1.5" Mecair VEM212 VNP212 VEM312 VNP312 VEM412 VNP412 Pulse Valve
Brand: Brando
SKU: DB112/G
Rating: 4.5 (112 reviews)

Home Products Diaphragm Repair Kit

DB112/G Diaphragm Repair Kit For 1.5" Mecair VEM212 VNP212 VEM312 VNP312 VEM412 VNP412 Pulse Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	DB112/G

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Plastic Bags, Cartons, Pallet
Delivery Time:	4-7 Days
Payment Terms:	L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Product Name:	DB112/G Diaphragm Repair Kit	Suitable Valves:	VNP212, VEM212, VNP312, VEM312, VNP412, VEM412
Diaphragm Material:	NBR (Buna)	Mounting Hole Size:	φ8mm
Diaphragm Outer Diameter:	φ116mm	Hole Center Distance:	φ120mm
Bleed Hole:	1	Spring:	1
No Of Diaphragm:	1	Packaging:	Individual Plastic Bag Sealed
High Light:	Mecair Diaphragm , Mecair Pulse Valve Diaphragm , Mecair Diaphragm Repair Kit

DB112/G Diaphragm Repair Kit For 1.5'' Mecair VEM212 VNP212 VEM312 VNP312 VEM412 VNP412 Pulse Valve

We produced series Mecair type diaphragm membrane repair kits, it is nice replacement for Mecair diaphragm. The below is DB112/G NBR diaphragm repair kit with stainless steel spring, which is for maintaining the Mecair pusle valves: VNP208, VEM208, VNP308, VEM308, VNP408, VEM408, VNP608, VEM608, VNP708, VEM708. The whole series diaphragm ordering number are DB16, DB18, DB112, DB114, DB116, DB120. If you are looking for others but don't know the diaphragm type of your valve, pls refer to the table below, thanks. If you have other problems or doubts, pls feel free to contact us.

YouTube video of DB112/G Diaphragm Repair Kit For 1.5'' Mecair Pulse Valve:

Main dimension of NBR Diaphragm For VEM212 VNP212 VEM312 VNP312:

DB112/G Diaphragm Repair Kit For 1.5" Mecair VEM212 VNP212 VEM312 VNP312 VEM412 VNP412 Pulse Valve 0

Details display of Membrane For Mecair VEM412 VNP412 Diaphragm Valve:

DB112/G Diaphragm Repair Kit For 1.5" Mecair VEM212 VNP212 VEM312 VNP312 VEM412 VNP412 Pulse Valve 1

Available Models of Diaphragm Valve Repair Kits For Mecair Pulse Valves:

Ordering code	Fitted valve code	Valve port size	Material
DB16	VNP206, VEM206, VNP306, VEM306	3/4''	Nitrile/Buna
DB18	VNP208, VEM208, VNP308, VEM308, VNP408, VEM408, VNP608, VEM608, VNP708, VEM708	1''	Nitrile/Buna
DB112	VNP212, VEM212, VNP312, VEM312, VNP412, VEM412	1-1/2''	Nitrile/Buna
DB114	VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714	1-1/2''	Nitrile/Buna
DB116	VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716	2''	Nitrile/Buna
DB120	VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720	2-1/2''	Nitrile/Buna
Diaphragm kits typically contain the replacement diaphragm(s) as well as the spring(s). The most popular kits are shown above. If you don't see the kit you need, pls don't hesitate to contact us.

Tips: The related solenoid coils and armature assembly are all supplied.

Factory Production Pictures of Solenoid Valve Diaphragm Kits:
