1 1/2" BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S

1 1/2" BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S

1 1/2" BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S
video
1 1/2" BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D40
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Diaphragm Repair Kit Mounting Hole Size: φ7mm
Diaphragm Material: NBR (Buna) Diaphragm OD: φ111.5mm
Center Distance: φ98mm Seat Material: Nylon
Seat OD: φ56.5mm Seat ID: φ36.5mm
Bleed Hole: 1 Spring: 2
Packaging: Individual Plastic Bag Sealed Suitable Valves: MF-Z-40S, DMF-Z-40S MF-Y-40S, DMF-Y-40S MF-ZM-40S, DMF-ZM-40S
High Light:

pneumatic valve diaphragm

,

rubber diaphragm

1 1/2'' BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S



The shown is a diaphragm valve repair kit for BFEC 1 1/2'' MF-Z-40S, DMF-Z-40S MF-Y-40S, DMF-Y-40S MF-ZM-40S, DMF-ZM-40S pulse jet valves, which is made of NBR with Nylon seat.



Working Principle:

Pulse valve parts including armature assembly, solenoid coil, diaphragm and valve body. The diaphragm keep close because of air pressure balance. Pulse timer send input signals so that the the coil make armature attracted and moving. Balance lost and balancing hole to release the pressure air in the back cavity of diaphragm quickly; the pressure air in the front cavity holds up the diaphragm to open the passage and the valve start one time jet. When the pulse signal disappears and the spring push the armature works immediately to resume the position, balancing hole been closed. Balance resumed in both cavity, so the valve stop jet.



YouTube video of 1 1/2'' BFEC DMF/MF Diaphragm Valve Repair Kit:



Main dimension of MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S Diaphragm:

1 1/2" BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S 0



Details display of BFEC Nylon Seat NBR Diaphragm Repair Kit:

1 1/2" BFEC Diaphragm Valve Repair Kit MF/DMF-Z-40S MF/DMF-Y-40S MF/DMF-ZM-40S 1



Available Models of BFEC DMF/MF Diaphragm Valve Repair Kits:

Ordering Code
Fitted Valve Code
Port Size
DTY
MF/DMF-T-25S, MF/DMF-T-40S, MF/DMF-T-50S, MF/DMF-T-62S,
MF/DMF-ZM-40S, MF/DMF-Y-40S, MF/DMF-Y-50S, MF/DMF-Y-62S,
MF/DMF-Y-76S, MF/DMF-YA-76S, MF/DMF-YB-76S, MF/DMF-Y-102S,
MF/DMF-Y-102SA, MF/DMF-Y-102SE, MF/DMF-ZF-40S, MF/DMF-Z-40S,
MF/DMF-Z-50S, MF/DMF-Z-62S, MF/DMF-Z-76S, MF/DMF-Z-102S
Tip: Secondary Diaphragm
D20A
DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20
3/4''
D25
DMF-Z-25, MF-Z-25, DMF-ZM-25, MF-ZM-25,
DMF-ZF-25, MF-ZF-25, DMF-Y-25, MF-Y-25,
DMF-T-20, MF-T-20
3/4'' & 1''
D40
DMF-Z-40S, MF-Z-40S, DMF-Y-40S, MF-Y-40S,
DMF-ZF-40S, MF-ZF-40S, DMF-ZM-40S, MF-ZM-40S,
DMF-T-25S, MF-T-25S
1'' & 1-1/2''
D50
DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S,
DMF-T-50S, MF-T-50S
2''
D62
DMF-Z-62S, MF-Z-62S, DMF-Y-62S, MF-Y-62S
2-1/2''
D76
DMF-Z-76S, MF-Z-76S, DMF-Y-76S, MF-Y-76S
3''
D102
DMF-Z-102S, MF-Z-102S, DMF-Y-102S, MF-Y-102S
4''
D102A
DMF-Y-102SA, MF-Y-102SA
4''
DZL-20B
DMF-ZL-B, MF-ZL-B
3/4''

Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
