Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System

Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System

    • Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System
    • Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System
    • Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System
    • Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System
  • Goyen Type 1-1/2" Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: ISO、CE
    Model Number: CA45DD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Port Size: G1-1/2'' Power: Solenoid
    Structure: Diaphragm Working Medium: Air
    Working Temerature: -5℃~+55℃ Working Pressure: 0.3~0.8Mpa
    Application: Dust Collector

    Goyen Type 1-1/2'' Diaphragm Pneumatic Pulse Valve With Dresser Nut For Baghouse Cleaning System

    CA45DD goyen type DD series electrimagentic pulse valve with dresser nut. According to working voltage, you can choose AC or DC solenoid coil. According to the working temperature and fluid viscosity , choose the material of seals and diaphragm. According to the working environment , choose the body material (common , corrosion resistance or Waterproof and etc).



    Youtube Video of CA45DD 1-1/2'' Diaphragm Pulse Valve With Dresser Nut:







    Construction:

    Body: Diecast aluminum
    Ferrule: 305 SS
    Armature: 430FR SS
    Seals: Nirtrile or FKM
    Spring: 304 SS
    Screws: 302 or 304 SS
    Outlet Slide Seal: EPDM or FKM
    Diaphragm Seat: PA-66(standard). FKM coated mild steel



    Technical Data:

    Model No. CA45DD
    Poet Size  G1-1/2''
    Number of Diaphragm  2
    Connection Type Right Angle with Dresser Nut
    Action Type  Pilot Operated
    Media Air
    Pressure  0.3~0.8Mpa
    Temperature  -5~+55℃
    Voltage  AC220V, AC110V, AC24V, DC24V
    Special voltages and special specifications, please contant us.



    Details About CA45DD Solenoid Pulse Valve:

    Details About CA45DD Solenoid Pulse Valve:



    Main Part of CA45DD electromagnetic pulse valve:

    Solenoid Coil

    Solenoid is the generic term for a coil of wire used as an electromagnet. It also refers to any device that converts electrical energy to mechanical energy using a solenoid. The device creates a magnetic field from electric current and uses the magnetic field to create linear motion. Common applications of solenoids are to power a switch, like the starter in an automobile, or a valve, such as in a sprinkler system.

    Armature

    An armature assembly for a solenoid valve allows for a valve member to be retained in the closed position through a biasing force being applied therein. A moveably supported armature bolt is movable between a first position and a second position. A valve member is coupled to the armature bolt and is configured to close with the armature bolt at the second position. An armature body is coupled to the armature bolt. A resilient member adapted to hold the armature bolt at the second position so as to retain the valve member in the closed position.

    Diaphragm

    The purpose of a diaphragm in a diaphragm type solenoid valve is to control the air within a certain space. These control valves can also be either open or closed, depending on the movement of the magnetic core.

    Main Body

    1.Different body material can be used in different working environment.
    2.Different Connection Type can be used in different place, suitable for different installation way.



    Maintenance Kits:

    Model  Nitrile  FKM Low Temperature–60°C (–76°F) MIN. Includes
    CA/RCA25DD K4502 K4503 K4522 Diaphragm kits include main and secondary diaphragms and all spring
    K4510 K4511 NA 2 dresser seals, 2 dresser nuts, 2 seal retainers
    K0380 K0384 NA o-ring, armature assembly, armature spring, ferrule



    Focus on your demands, Offer you best solution:

    √ Contact us if some points you have doubt
    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing


    Welcome to your any question and inquiry!
