Goyen Type 1" Outlet 1-1/2" Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors

Goyen Type 1" Outlet 1-1/2" Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors

    • Goyen Type 1" Outlet 1-1/2" Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors
    • Goyen Type 1" Outlet 1-1/2" Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors
    • Goyen Type 1" Outlet 1-1/2" Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors
  • Goyen Type 1" Outlet 1-1/2" Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: ISO、CE
    Model Number: CA25FS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Inlet: G1'' Outlet: G1-1/2''
    Power: Solenoid Structure: Diaphragm
    Connection Type: Flanged Inlet Port Working Medium: Air
    Working Pressure: 0.3~0.8Mpa Application: Dust Collector

    Goyen Type 1'' Outlet 1-1/2'' Inlet Flanged Valve for Reverse Pulse Jet Systems In Dust Collectors



    CA/RCA-FS Series right angle with inlet port flange connection solenoid pulse jet valve, Outlet connect with blow tube directly.Outlet at 90° to inlet.
    The inlet diameter of the FS valve is larger than the outlet, and a venturi injection structure is formed in the valve body, so it has the characteristics of low resistance, fast response and high Cv value.



    Specification of CA25FS Solenoid Pulse Valve:

    Model No. CA25FS
    Port Size  1'' outlet 1-1/2'' inlet
    Valve Type Diphragm Valve
    Action Type Pilot Operated
    Connection Type  Flanged Inlet Port
    Temperature Range  -5~+55℃
    Pressure  0.3~0.8Mpa
    Body Material  Diacast Aluminum
    Seal Material  NBR(common, all available)
    Voltage  AC24V, AC110V, AC220V, DC24V



    Overall Dimension of CA25FS Dust Collector Valve:

    ca25fs overall dimension

    Deatails of CA25FS Diaphragm Electromagentic Pulse Valve:

    CA45FS Details



    Connecting surface of CA25FS Solenoid Pulse Valve:

    Connecting surface

    Benefits of Goten Type Flanged Valve :


    -For noxious substance control and environmental dust management
    Cost savings
    -Increased pulse efficiency, reduced energy consumption
    -Durable materials and wide temperature range enhance lifespan
    -Longer filter life, lower dust collector OPEX
    Compliance
    -With environmental and health & safety regulations
    Ease of installation
    -No welding required with 90° connections directly onto square tanks
    -Camlock adapter available for attachment to round tanks





    How do pulse clean system work?

    A reverse pulse (often called a pulse jet or reverse jet) filter cleaning system is a simple action that has significant results.
    A simple explanation of a reverse pulse filter cleaning system is as follows:
    in normal dust collector operation, air flows from the outside of the filter media to the center of the filter.
    The dust is filtered out and left on the outside surface of the filter.
    To clean off this dust, a blast of compressed air is shot down the center of the filter and works outward taking the dust off of the surface of the filter.
    In a downflow dust collector, the dust is captured by that downward airflow and eventually deposited in the collection bin.



    Maintenance:

    Before conducting any maintenance activity on the system ensure that components are fully isolated from pressure and power supplies. Pressure and power should not be reapplied until the valve has been fully assembled.
    Diaphragm and pilot inspection should be conducted annually.



    Nirtrile FKM Low Temp –60°C (–76°F) MIN. Includes
    k2501 k2503 k2504 Diaphragm kits include main and secondary diaphragms (where required) and all springs.
    K0380 K0384   O-ring armature assembly, armature spring, ferrule
