1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V

1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V

    • 1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V
    • 1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V
    • 1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V
    • 1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V
  • 1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: 4V330C-08

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: Negotiation
    Packaging Details: Individual box, Carton, Pallet
    Delivery Time: 4-8 days
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 100000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: 4V330C-08 AirTAC Type Pneumatic Solenoid Valve Port Size: 1/4''
    Type: Double Solenoid, 3 Position 5 Way Working Medium: 40 Micron Filltered Air
    Body Material: Aluminum Alloy Motion Pattern: Inner Piloted Type
    Connection: Female Thread(G, NPT, PT, BSP, BSPT) Voltage: DC12V, DC24V, AC24V, AC110V, AC220V, AC380V
    Working Temperature: 5~50°C Pressure: 0.15MPa~0.8MPa
    Application: Automation Equipment

    1/4'' NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V



    A 4V330C-08 pneumatic solenoid valve is a switch that directs air to any pneumatic equipment (usually an actuator), allowing relatively small signals to control large equipment. It is also the interface between the electronic controller and the pneumatic system. The valve allows pneumatic control of position, flow, pressure and temperature. Pneumatic solenoid valves are found in many industries. The aircraft uses pneumatic valves to control the pressure and flow of hot air from the engine to the windshield to prevent icing and rain. Food and beverage manufacturers use them to make, distribute or preserve food and beverage products. Brando pneumatic valve has the characteristics of high reliability, low power consumption and long service life. They have pre-wired connections to make installation, maintenance and control simple.



    YouTube video of 4V330C-08 AirTAC Type 5/3 Way Pneumatic Solenoid Valve:



    Main dimension of 4V330C-08 AirTAC Type Solenoid Valve Close Center:

    1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V



    Details display of 4V330C-08 5 Way 3 Position Air Control Solenoid Valve:

    1/4" NPT 4V330C-08 AirTAC Type Pneumatic Solenoid Valve 5/3 Way Close Center AC220V DC24V



    Specifications of 4V300 Series AirTAC Type Pneumatic Solenoid Valves:

    Model
    4V310-08
    4V320-08
    4V330C-08
    4V330E-08
    4V330P-08
    4V310-10
    4V320-10
    4V330C-10
    4V330E-10
    4V330P-10
    Fluid
    Air(to be filtered by 40 μ m filter element)
    Acting
    Internal pilot or external pilot
    Port Size
    In=Out=Exhaust=1/4''
    In=Out=3/8'' Exhaust=1/4''
    Orifice Size
    25.00 mm2 (Cv=1.40)
    18.00 mm2 (Cv=1.00)
    30.00 mm2 (Cv=1.68)
    18.00 mm2 (Cv=1.00)
    Valve Type
    5 way 2 position
    5 way 3 position
    5 way 2 position
    5 way 3 position
    Operating Pressure
    0.15~0.8MPa(21~114psi)
    Proof Pressure
    1.5MPa(215psi)
    Temperature ℃
    5~50
    Material of Body
    Aluminum alloy
    Max. frequency
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec



    Factory production video of 4V Series AirTAC Type Pneumatic Solenoid Valves:



    Advantages of pneumatic valves:
    Pneumatic valves are usually operated by air captured during prior or ongoing operations. Because they are used to trigger larger valves and do not cost more, they are a cheaper and cheaper way to power solenoid valves. Compressed air can produce a tremendous amount of force, which can be applied to another valve and recycled when the job is done. Its actual design or footprint is very small, so it does not add much weight to the mechanism.

    Pneumatic solenoid valve types:
    Valves can be specified for internal or external driving. Valves can also be classified according to the number of connections or paths they contain. External pilot valves use external pressure sources. Internal driving uses an internal air pressure source. Two-way pilot valves are available for dust collection systems. Internally driven pilot valves with four-way connections are usually found in pneumatic operations and are used to move double acting cylinders. Pneumatic solenoid valves can be designed to stack.



    Focus on your demands, Offer you best solution:



    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing



    Welcome to your any question and inquiry!
