BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V

BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V

    • BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V
    • BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V
    • BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V
    • BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V
  • BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: 4V310-08

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: $4 to $10 per pc
    Packaging Details: Individual box, Carton, Pallet
    Delivery Time: 4-8 days
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 100000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: 4V310-08 AirTAC Type Pneumatic Solenoid Valve Pipe Sizes: Inlet=Outlet=Exhaust=1/4''
    Connection Type: Female Thread(G, PT, NPT, BSP) Valve Type: Single Solenoid, 2 Position 5 Way
    Action Type: Internal Pilot Operated Seals Material: NBR
    Body Material: Aluminum Alloy Enameled Wire Material: Copper
    Operating Temperature: 5-50℃ Operating Pressure: 0.15-0.8MPa (21-114psi)
    Voltages: AC220V, AC110V, DC24V, Or DC12V

    BSP 1/4'' 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V



    4V310-08 Pneumatic solenoid valve, single solenoid, 5/2 way, 1/4" port, internal pilot, terminal entry, 300 series. The electric directional control valve controls the air flow by energizing the solenoid valve. These components are designed to stop, start or change the direction of the airflow.



    We offer multiple port and position configurations. Most air control valves are available with AC220V, DC24V, AC110V, AC24V or DC12V solenoid coils. Select from 5/2 way, 5/2 way or 3/2 way.



    When selecting the thread type, refer to the following criteria:
    NPT-Universal American Standard Tapered Pipe Thread
    M-Metric Thread M
    RP or G (BSPP)-inch standard pipe (parallel) thread
    PT-JIS taper pipe thread



    YouTube video of 4V310-08 AirTAC Type 5/2 Way Pneumatic Solenoid Valve:



    Main dimension of G1/4'' 4V310-08 5 Way 2 Position Solenoid Air Valve:

    BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V



    Details of 1/4 Inch 4V310-08 Airtac Type Single Solenoid Pneumatic Valve:

    BSP 1/4" 4V310-08 AirTAC Type Pneumatic Solenoid Valve 5/2 Way Single Solenoid DC12V DC24V



    Specifications of 4V Series Internal Pilot Operated AirTAC Type Solenoid Valves:

    Model
    4V310-08
    4V320-08
    4V330C-08
    4V330E-08
    4V330P-08
    4V310-10
    4V320-10
    4V330C-10
    4V330E-10
    4V330P-10
    Fluid
    Air(to be filtered by 40 μ m filter element)
    Acting
    Internal pilot or external pilot
    Port Size
    In=Out=Exhaust=1/4''
    In=Out=3/8'' Exhaust=1/4''
    Orifice Size
    25.00 mm2 (Cv=1.40)
    18.00 mm2 (Cv=1.00)
    30.00 mm2 (Cv=1.68)
    18.00 mm2 (Cv=1.00)
    Valve Type
    5 port 2 position
    5 port 3 position
    5 port 2 position
    5 port 3 position
    Operating Pressure
    0.15~0.8MPa(21~114psi)
    Proof Pressure
    1.5MPa(215psi)
    Temperature ℃
    5~50
    Material of Body
    Aluminum alloy
    Max. frequency
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec
    4 cycle/sec



    Brando Factory Production of 4V Series AirTAC Type Pneumatic Solenoid Valves:



    Function of 4V series solenoid valves in pneumatic system:

    Pneumatic valves are among the collection of gears responsible for controlling the pressure, speed, and quantity of air as it passes through a pneumatic system. These systems depend on the strength of dense air to send out power; can be found in innumerable industrial purposes, from pneumatic pressure control gear to diesel engines.



    In double working cylinders, air stress is supplied off and on to the comparative surface of the pressure supplier, creating a drivingpower and a withdrawing force. As the active part of the pressure provider is trivial, the drive formed through the withdrawal is comparatively weak.


    Pneumatic valves moves air all through a bigger pneumatic system by either permitting or restraining the stream of condensed air, whose power is then meant to control a device. Because valves can contain different areas of entrance for air, generating diverse flow models, valves are categorized on the basis of the amount of ports they own and the flow-paths they generate.
