G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve

G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve

    • G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve
    • G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve
    • G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve
    • G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve
  • G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: 6013

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Inner Box, Carton, Pallet
    Delivery Time: 4-8 days
    Payment Terms: L/C, T/T, Western Union,Paypal
    Supply Ability: 150000 sets per month
    Contact Now
    Detailed Product Description
    Product Name: Burkert Type 6013 Plunger Valve Port Size: G1/8'', G1/4'', G3/8''
    Orifice Size: 2.0mm, 2.5mm, 3.0mm, 4.0mm, 6.0mm Medium: Compressed Air, Water, Hydraulic Oil
    Body Material: Brass Seal Material: FKM (Viton)
    Function: 2/2 Way Normally Closed Action Type: Direct Acting
    Fluid Temperature: -10 To +100°C Working Pressure: 0 - 12bar
    Voltage: AC110V, AC220V, DC24V



    G1/4'' Inch 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve



    Product description of burkert type 6013 plunger valve 2/2 way direct acting:
    1. Valve 6013 is a direct-acting plunger valve up to diameter of DN 6.0.
    2. The stopper and plunger guide tube are welded together to enhance pressure resist-ance and leak-tightness.
    3. Direct acting solenoid valve system with brass body. For neutral gases and liquids such as compressed air, natural gas, water and hydraulic oil & Technical vacuum.
    4. Various seal material combinations are available depending on the application.
    5. The coils are moulded with polyamide or with chemically resistant epoxy.



    Overall dimension of G1/4'' Burkert Type 6013 Plunger Valve 2/2 Way Direct Acting:

    G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve



    Technical data of Burkert Type 2/2 Way Direct Acting 6013 Plunger Solenoid Valve:

    Orifice Size (mm) Port Size (Inch) Value Water (m³/h) Opening response times (ms) Closed response times (ms)
    2.0 G1/8'' 0.12 20 30
    2.0 G1/4'' 0.12 20 30
    2.5 G1/8'' 0.16 20 30
    2.5 G1/4'' 0.16 20 30
    3.0 G1/8'' 0.23 20 30
    3.0 G1/4'' 0.23 20 30
    3.0 G3/8'' 0.23 20 30
    4.0 G1/4'' 0.30 20 30
    4.0 G3/8'' 0.30 20 30
    6.0 G1/4'' 0.55 20 30
    6.0 G3/8'' 0.55 20 30



    Details of Burkert Type 6013 1/4'' Brass Body FKM Seal Electromagnetic Valve:

    G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve



    Packaging of BURKERT Type 2/2 Way Direct Acting Brass Body Plunger Valve:

    G1/4" 24VDC 220VAC Burkert Type 6013 2 Way Brass Body FKM Seal Plunger Solenoid Valve

    Youtube video of G1/4'' FKM Seal 6013 Burkert Type 2 Way Brass Solenoid Valve:



    Danger of explosion caused by electrostatic charge!
    If there is a sudden discharge from electrostatically charged devices or persons, there is a danger of explosion in the Ex area.
    • Using suitable measures, ensure that no electrostatic charges can occur in the Ex area.
    • Clean the device surface by gently wiping it with a damp or antistatic cloth only.



    General Hazardous Situations.
    To prevent injuries:
    • Ensure that the system cannot be activated unintentionally.
    • Installation and maintenance work may be carried out only by authorized technicians with the appropriate tools.
    • After an interruption in the power supply or pneumatic supply, ensure that the process is restarted in a defined or controlled manner.
    • The device may be operated only when in perfect condition and in consideration of the operating instructions.
    • The general rules of technology must be observed for application planning and operation of the device.



    Danger – high pressure!
    When reaching into the system, there is an acute risk of injury.
    • Before dismounting pneumatic lines and valves, turn off the pressure and vent the lines.
    • During the installation, make certain the flow direction is correct.
    • Observe applicable accident prevention and safety regulations for pressurized devices.
