3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz

3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz

    • 3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz
    • 3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz
    • 3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz
    • 3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz
  • 3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: MSV1078/6

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Inner Box, Carton, Pallet
    Delivery Time: 4-7 days
    Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
    Supply Ability: 80000 sets per month
    Contact Now
    Detailed Product Description
    Product Name: 1078/6 CASTEL Type Solenoid Valve Port Size: 3/4'' ODF
    Action: Diaphragm Pilot Operated Function: Normally Closed
    Voltages: DC4V, AC110V, AC220V, AC230V Refrigerants: CFC, HCFC, HFC
    Medium Temperature: -35 To +105℃ Min. Operating Pressure: 0.05MPa
    Max. Operating Pressure: 2.5MPa Application: Commercial Refrigeration Systems And On Civil And Industrial Air Conditioning Plants

    3/4'' ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz



    1078/6 solenoid Valve is one of the castel type MSV seies solenoid valves. Castel type MSV series normally closed solenoid valves for refrigeration systems with direct acting principle or membrane / piston pilot operated. They can be installed on the three main branches of a plant (liquid line, suction line, hot gas line). Solenoid valves normally closed for industrial use with direct acting principle or membrane / piston pilot operated. The solenoid valves illustrated in this chapter are designed for installation on commercial refrigeration systems and on civil and industrial air conditioning plants that use the following refrigerant fluids: CFC, HCFC, HFC, and so on.



    Main dimension of 3/4'' ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve:

    3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz



    Technical parameters of Castel Type MSV Series Diaphragm Pilot Operated Solenoid Valve:

    Model No.

    SAE or ODF

    Port Size

    Operating Principles

    KV

    (m³/h)

    MSV-1020/2 1/4''SAE Direct Acting 0.175
    MSV-1020/3 3/8''SAE Direct Acting 0.23
    MSV-1028/2 1/4''ODF Direct Acting 0.15
    MSV-1028/3 3/8''ODF Direct Acting 0.23
    MSV-1064/3 3/8''SAE Diaphragm Pilot Operated 0.8
    MSV-1064/4 1/2''SAE Diaphragm Pilot Operated 0.8
    MSV-1068/3 3/8''ODF Diaphragm Pilot Operated 0.8
    MSV-1068/4 1/2''ODF Diaphragm Pilot Operated 0.8
    MSV-1070/4 1/2''SAE Diaphragm Pilot Operated 2.2
    MSV-1070/5 5/8''SAE Diaphragm Pilot Operated 2.61
    MSV-1078/4 1/2''ODF Diaphragm Pilot Operated 2.2
    MSV-1078/5 5/8''ODF Diaphragm Pilot Operated 2.61
    MSV-1078/6 3/4''ODF Diaphragm Pilot Operated -
    MSV-1078/9 1 1/8''ODF Diaphragm Pilot Operated 10
    MSV-1078/11 1 3/8''ODF Piston Pilot Operated 16
    MSV-1090/5 5/8''SAE Diaphragm Pilot Operated 3.8
    MSV-1090/6 3/4''SAE Diaphragm Pilot Operated 4.8
    MSV-1079/7 7/8''ODF Diaphragm Pilot Operated 2.61
    MSV-1079/11 1 3/8''ODF Diaphragm Pilot Operated 10
    MSV-1079/13 1 5/8''ODF Piston Pilot Operated 16
    MSV-1098/7 7/8''ODF Diaphragm Pilot Operated 5.7
    MSV-1099/9 1 1/8''ODF Diaphragm Pilot Operated 5.7
    MSV1099/11 1 3/8''ODF Piston Pilot Operated 10



    Details of 3/4'' ODF 1078/6 CASTEL Type Normally Closed Refrigeration Solenoid Valve:

    3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz



    Packaging of 1078/6 3/4'' Inch ODF Soldering Castel Type Electromagnetic Valve:

    3/4" ODF 1078/6 CASTEL Type Diaphragm Pilot Operated Solenoid Valve 220/230V 50/60Hz

    Youtube Video of CASTEL Type 1078/6 3/4'' Inch ODF Diaphragm Pilot Operated Solenoid Valve:



    These valves can work with zero pressure differential.
    The valves series 1064 ; 1068 ; 1070 ; 1078 (excluded /11 , /13 , and /M42) ; 1079 (excluded /13 , /M42 , and /17) ; 1090 ; 1098 (excluded /9) ; 1099 (excluded /11) are pilot-operated diaphragm solenoid valves. Their operation depends not only on the magnetic field produced by the current flow into the coil, but also on a minimum inlet pressure, which is necessary to:


    1. open the diaphragm and keep it lifted off the main opening


    2. close the diaphragm and ensure the tightness on the main opening


    Opening/closing of main valve seat is controlled by the diaphragm while opening/closing of pilot seat is controlled by the mobile plunger of the coil. These valves cannot work with zero differential pressure.



    These valves cannot work with zero differential pressure.
    The valve series 1034 ; 1038 ; 1040 ; 1048 ; 1049 ; 1050 ; 1058 ; 1059 ; 1078 (/11 , /13 , /M42) ; 1079 (/13 , /M42 , /17) ; 1098/9 ; 1099/11 are piston pilot-operated valves. Their operation depends not only on the magnetic field produced by the current flow into the coil, but also on a minimum inlet pressure, which is necessary to:


    1. open the piston and keep it lifted off the main opening


    2. close the piston and ensure the tightness on the main opening


    Opening/closing of main valve seat is controlled by the piston, while opening/closing of pilot seat is controlled by the mobile plunger of the coil.
