2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35

2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35

    • 2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35
    • 2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35
    • 2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35
    • 2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35
  • 2/2 Way NC 1-1/4" Inch Direct Acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35

    Product Details:

    Place of Origin: China
    Brand Name: BRANDO
    Certification: ISO、CE
    Model Number: 2W350-35

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Brand: BRANDO Model No.: 2W350-35
    Body Material: Brass Seal: NBR,EPDM Or VITON
    Port Size: G1-1/4'' Inch Media: Air, Water, Oil, Gas
    Connection: Female Thread Motion Pattern: Direct Drive

    2/2 Way NC 1-1/4'' Inch Direct-acting AC220V Brass Body Water Treatment UW-35 Uni-D Type 2W350-35



    The valve below is UW-35 Uni-D Type Solenoid Valve 2W350-35.2/2 Way Normal Close Type Operated Solenoid Valve for water, gas, air, which viscosity fluids (< 20 cst). Able to be operated directly under low pressure. Solenoid valves consist of a coil, plunger and sleeve assembly. A plunger opens or closes the orifice by raising or lowering within a sleeve tube by energising the coil.



    2W350-35

    2W: Two Position Two Way Direct Drive Type Solenoid Valve

    350: Aperture of Flow Rate is 35 mm

    35: G1-1/4'' Inch



    2/2 Way Normal Close Solenoid Valve 2W350-35 Technical Data:



    Model 2W350-35
    Motion Pattern Direct Drive
    Type 2 Position 2 Way Normal Close
    Aperture of flow rate 35 mm
    Port Size 1-1/4''
    CV

    24 m3/h

    Working Pressure Water, Oil: 0~5 kgf/cm2    Air, Gas: 0~7 kgf/cm2
    Max. Pressure Resisitance 10.5 kgf/cm2
    Operating Temperature Range -5~80 ℃
    Material Body: Brass    Seal: NBR, EPDM, VITON
    Vlotage AC220V
    Vlotage Range +-10%



    Overall Dimension Drawing of G1-1/4'' Inch 2W350-35 Brass Body:

    Overall Dimension Drawing



    Disassembly diagram of 2W350-35 Solenoid Valve NC Direct Drive:



    Disassembly diagram



    Details of 24VDC/220VAC 2W350-35 solenoid water valve:



    details



    More Details of  UW-35 Uni-D Type Water Treatment Solenoid:





    How Normal Close 2W Series Solenoid Valve Works:



    Solenoid valves consist of a coil, plunger and sleeve assembly.Solenoid valve function involves either opening or closing an orifice in a valve body, which either allows or prevents flow through the valve. A plunger opens or closes the orifice by raising or lowering within a sleeve tube by energising the coil.
    In normally closed valves, a plunger return spring holds the plunger against the orifice and prevents flow. Once the solenoid coil is energised, the resultant magnetic field raises the plunger, enabling flow.





    2W series solenoid valve application:



    Used in medical machinery, solar energy, cleaning equipment, food machinery, burners, welding and cutting, fire safety, environmental water treatment, machinery manufacturing and other industries.2W series solenoid valve for  liquid, water, gas, hot water, oil, gas, etc.

    The role of the solenoid valve is to use a moving iron core to open or close the valve, allowing the liquid flow or sealing, no leakage. This is a very important process in fluid and gas control automation, and different types of solenoid valves perform the same job in different ways.
