DC12V Solenoid Coil For AEB 2386310000 / 2386370000 / 2386350000 Injectors Rail

DC12V Solenoid Coil For AEB 2386310000 / 2386370000 / 2386350000 Injectors Rail

This 12VDC solenoid coil is applied in AEB Type 2386310000 / 2386370000 / 2386350000 Injectors Rail. Gasoline car injection solenoid valve structure is mainly composed of external solenoid valve coil, c-type magnetic guide plate, fixed iron core, cylinder, spring, valve core, valve seat and air outlet. The drive circuit is used to control the fast closing of electromagnetic circuit. The reverse spring force of the spring closes quickly to allow high speed operation to control the injection of gas fuel. Automobile solenoid valve is the actuator of electronic control system. If the solenoid valve is running, but the solenoid valve is working, there are certain conditions. If it rings all the time, it may indicate that the solenoid valve is damaged or malfunctioning.

Technical parameter of AEB Type Injectors Rail Solenoid Coils:

Main dimension of Solenoid Valve Coil For AEB Type Injector Rail:

Detail enlargement of Solenoid Valve Coil For AEB Type Injectors Rail:

Applied in AEB 2386310000 / 2386370000 / 2386350000 Injectors Rail:

Production display of DC12V Solenoid Valve Coil For ABE Type Injector Rail:

More details about Solenoid Coil For AEB 2386310000 / 2386370000 / 2386350000 Injectors Rail in below Youtube Video:

Production details of Electromagnetic coil:
A solenoid coil is made by prepreparing the prepared skeleton onto the shaft of an automatic winding machine. According to the programming, that is, the number of windings, start the winding and remove the winding. After welding treatment, test resistor qualified, put into a drying box for drying. The drying temperature is controlled at about 80 degrees, and the drying time is over 4 hours. For all solenoid valve coil manufacturers, the above steps are basically the same.

The most critical part below is sealing the dry coil. There are three plastic sealing methods on the market, one is ordinary thermoplastic polypropylene PP plastic; The second is thermosetting DMC unsaturated polyester fiber reinforced plastic, and the third is thermosetting epoxy resin molding plastic packaging, the first is common plastic is not recommended for users to use, because this product packaging products will be short-circuit or decomposed into a long period of time, mainly PP material and skeleton material together. Water entering the air will not meet the requirements of the cooking test. The second method can meet the requirements of water immersion test, but does not meet the requirements of cooking test. What is cooking test is to put the product into 100 boiling water boil for 2 hours, quickly put in cold water for 1 hour, then put in boiling water for 1 hour, and then put in cold water for 1 hour, the surface water is blown off, waveform and day waveform table superposition. The measurement will not short circuit. Third, it has excellent electrical insulation, high dielectric strength, heat resistance, corrosion resistance, flame retardancy, forming the heat resistance of the index is 1500 degrees, good mechanical strength, high dielectric properties, resistance to leakage) arc resistance, suitable for use with different ions, or in the environment of corrosive gas, items can be exposed outdoors for a long time.

Welcome to your any question and inquiry!
