Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System

Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System

    • Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System
    • Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System
    • Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System
    • Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System
  • Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: ISO、CE
    Model Number: MVRS-83000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Pcs,Sample Available
    Price: negotiation
    Packaging Details: PVC bag, inner box, carton, than packed by pallet; also can be packed by color card and can be customized
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Power: Pneumatic Temperature Of Media: Normal Temperature
    Application: Dedusting Media: Air
    Valve Type: Pulse Valve Material: NBR

    Repair Kit of BUHLER Type Pulse Valve Membrane MVRS-83000 in Pulse Jet Blowing System


    Diaphragm is one of the important components of electromagnetic pulse valve, high quality electromagnetic pulse valve must be equipped with high-performance diaphragm, electromagnetic pulse valve in the high-frequency open and closed working state for a long time, high quality diaphragm must have tensile strength, good sealing, corrosion resistance, anti-aging.


    The high quality nitrile butadiene rubber selected by electromagnetic pulse valve diaphragm has the characteristics of extremely strong oil resistance, acid resistance, high temperature resistance, alkali resistance and so on.


    Model BUHLER pulse valve diaphragm
    Material NBR,or customized by your condition
    Hole number for mounting 3
    Working temperature -20℃--80℃
    Working pressure 0.2Mpa-0.6Mpa
    Working medium Water,Clean Air
    Diaphragm working life More than 1 million cycles



    Diaphragm installation in pulse valve,widely application in variuous Dust Filter Collector,such as Reverse Pulse Jet Dust Collector & Pulse Jet Bag Filter



    Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System    Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System



    Diaphragm determine the working life of the whole dust collector system



      Repair Kit Of BUHLER Type Pulse Valve Membrane MVRS-83000 In Pulse Jet Blowing System







    Common problems and solutions of electromagnetic pulse valve:



    One, electromagnetic pulse valve in the installation, often appear problems and solutions:

    1, fault phenomenon: some valves do not work, other valves are normal; Cause analysis: check the wiring connection and coil of the valve; Rule out: replace accessories.



    2, fault phenomenon: all valves can not open, but the pilot part has action; Cause analysis: check whether the gas pressure is too low; Elimination method: leak detection.



    3. Fault phenomenon: some valves cannot be closed with air leakage; Cause analysis: impurities adsorbed on the membrane, moving iron core stuck phenomenon; Elimination method: clean the diaphragm, check the integrity of the diaphragm, check the moving iron core and air plug.



    4, fault phenomenon: solenoid valve closed slowly; Cause analysis: diaphragm throttle hole is blocked; Elimination method: dredge the diaphragm throttle hole.



    5. Fault phenomenon: all valves cannot be closed, there is air leakage, and the air bag pressure cannot be established; Cause analysis: 1, Y valve with the same air bag several valves leakage caused by all valve leakage false image; 2, z-valve, valve air inlet and the opposite installation of the nozzle; Corresponding elimination methods: 1. Air leakage detection; 2. 2. Reinstall.





    About Diaphragm,I want to tell you some truth



    Actually, the service life of pulse valve diaphragm can not completely sure, basically be to see you when using diaphragm condition, temperature, acid, alkaline etc, and you have to type the electromagnetic pulse valve is suitable for you use models of diaphragm, if it is not consistent, will shorten the service life of pulse valve diaphragm, of course, the most important thing is to see the quality of the manufacturer, do not covet is cheap to buy some poor quality of the pulse valve diaphragm, although that is account for petty gain, is no use, disguised ate a big loss.
    We have been this line more than 10 years,almost all of our customers were satisfactory with our quality and credibility.If you truely have the present demand of these items,could you please take priority to us?





    If you are interesting,pls contact us without any hesitation
