9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type

9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type

    • 9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type
    • 9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type
    • 9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type
    • 9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type
  • 9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: BB09131525EX

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Inside box, carton, pallet
    Delivery Time: 5-8 days
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 200000 pcs per month
    Contact Now
    Detailed Product Description
    Type: Water Valve Accessories Coils Material: Brass, Epoxy Resin
    Product Name: Pneumatic Solenoid Valve Coils Voltage: DC24V/AC220V
    Hole Size: 9 Mm Power: Solenoid Control
    Color: Black (Other Color Can Be Customized) Application: Water Solenoid Valve Automatic Control
    Insulation Class: H, B, F Connection: Cable

    9 mm Inside Hole Explosion-proof Electromagnetic Water Valve Coil 0960/0920 Type



    Generally speaking, the outer diameter and height of the static iron core seat can be combined with our explosion-proof coil to form an explosion-proof solenoid valve. Attention should still be paid to the following matters during use:


    1. Check whether there is an explosion-proof mark before installation. If yes, whether the explosion-proof mark is suitable for use in hazardous places:


    2. Check the power supply and voltage must be consistent with the nameplate mark. The AC type coil must not be energized at no load. Because the coil is equipped with an overcurrent protection device, when the no-load is energized, the current increases several times, and the overcurrent protection acts instantaneously, causing the coil. Open circuit; in addition, an overvoltage protection device is also provided in the coil, when the use voltage exceeds 20% of the rated voltage, the protection device will be caused to act, resulting in permanent disconnection of the coil;


    3. The power must be cut off during inspection or repair;


    4. Explosion-proof solenoid valve coil, automobile valve coil, explosion-proof coil, electromagnetic coil introduction cable is 3-core cable, in which yellow-green two-color or black is the grounding wire, the grounding wire must be reliably grounded, and must not be connected to the power supply, otherwise there is danger of leakage and electric shock;



    Technical parameter of 9 mm explosion-proof solenoid valve coils:

    Model No. BB09131525EX
    Normal Voltages: DC24V/AC220V; Or OEM
    Normal Power AC:28VA DC:30W
    Insulation Class H, B, F
    Connection Type Cable
    Application 2W/2S Water solenoid valve
    Weight 250 g
    Hole size 9 mm



    Main dimension of explosion-proof water electromagnetic valve coils:

    9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type



    Multi-angle display of explosion-proof water solenoid coils 0960/0920 Type:

    9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type



    Automatic winding machine of AC220V/DC24V explosion-proof water valve coils:

    9 Mm Inside Hole Explosion Proof Electromagnetic Water Valve Coil 0960/0920 Type



    The reason why the magnetic strength of the solenoid coil is weak:

    For the use of explosion-proof coils, people often find a problem, the magnetic is not very strong, so it is not working in use. Then, in response to this problem, people need to know the reasons for solving the problem. So what is the reason inside?


    1. The product has not been used for a long time, causing the magnetic inside to gradually disappear. When it is used again, the related magnetic field cannot be established. In this regard, when people use solenoid coils, they should not be used for too long, even if they are not needed, please pay attention to them to start them regularly to ensure that the magnetic field will not disappear, so naturally it will not malfunction.


    2. The method used is wrong. If the method is not correct for the use of the solenoid coil, there is a problem. At this time, people need to look at the relevant instructions to do so. This can effectively improve the related magnetic properties. It is important to know the reasons for this so that you can really improve its magnetic properties.


    In short, the use of solenoid coils is correct and cannot be used for a long time, which naturally leads to various problems in the product.



    How can we extend the life of explosion-proof solenoid coil:

    In order to ensure the normal use of the solenoid valve, people should take corrective measures to prolong the service life of the explosion-proof coil, which is able to effectively reduce the probability of failure. So, how can we extend the life of the solenoid valve coil? Here is a brief introduction.


    Controlling the current: The control of the current of the solenoid valve coil is an important point. It should be known that although there are many types of coils, the current requirements of different types of models are also very different. Before using, it is necessary to understand the current magnitude, and When using it, it should be controlled according to the current. In particular, it is necessary to avoid the phenomenon that the current is large, and a large current also causes the use problem.


    Avoid overload use: The use of solenoid valve coils still needs to avoid overloading. It should be known that although long-term use can ensure the performance of the solenoid valve, it will also lead to an increase in temperature during use, and the rise in temperature will result in The occurrence of burnout does not help to extend the service life.


    Extending the service life of the solenoid valve coil can ensure the normal use of the solenoid valve. It is therefore necessary to pay attention to the use of the solenoid valve. It is necessary to take correct measures to actively carry out maintenance work.
