CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm

CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm

    • CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm
    • CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm
    • CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm
    • CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm
  • CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: BB12039508

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: $1-$3 per set
    Packaging Details: Inner Box,Carton,Pallet
    Delivery Time: 4 - 9 days
    Payment Terms: L/C, T/T, Western Union,Paypal
    Supply Ability: 200000 pieces per month
    Contact Now
    Detailed Product Description
    Model: CY123 Coils Material: Plastic, Copper
    Product Name: Pulse Solenoid Valve Coils Voltage: DC12V/DC24V/AC110V/AC220V
    Hole Size: 12mm Power: Solenoid Operated
    Color: Gray (Other Color Can Be Customized) Application: Pulse Control Solenoid Coils
    Insulation Class: F, H Connection Type: DIN43650A

    CY123 N282 C53056N Goyen Type Pulse Jet Valve Coil Inner Hole diameter 12mm High 39.5mm



    Product features of CY123 N282 C53056N Goyen Type Pulse Jet Valve Coil Inner Hole diameter 12mm High 39.5mm:



    1. Adopt high quality enameled wire certified by CE.


    2. Low carbon high permeability steel is used as the magnetic conductive material.


    3. Specially made coating materials such as PA66.PBT.PPS.BMC to ensure product quality.


    4. The insulation level of the electromagnetic coil reaches the H.N.C rating.


    5. The protection level of the electromagnetic coil reaches IP65.IP67.


    6. There are special series of explosion-proof electromagnetic coils used in explosion-proof environments such as coal mines and oil fields, and waterproof electromagnetic coils for underwater use.


    7. If you have special requirements, please contact us.



    Technical parameter of CY123 goyen type pulse jet valve coil:

    Model No. BB12039508
    Normal voltage DC12V/DC24V/AC110V/AC220V
    Normal power AC:25VA DC20W
    Insulation class H, F
    Connection type DIN43650A
    Application Goyen type pulse solenoid valve
    Weight 142.5 g



    Mian dimension of pulse diaphragm valve N282 solenoid coils:

    CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm



    C53056N DC24V/AC220V pulse solneoid valve coils for automatic control:

    CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mmCY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm



    Application of Hole diameter 12mm High 39.5mm pulse valve coils:

    CY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mmCY123 N282 C53056N Pneumatic Solenoid Coil Inner Hole Diameter 12mm High 39.5mm



    The coil is the switch of the solenoid valve, and the pulse electromagnetic coil is the switch of the pulse solenoid valve. The working principle and details of the right angle pulse valve with coil control are described below:



    The right-angle electromagnetic pulse valve controls the opening and closing of the valve body relief hole according to the pulse controller signal to realize the injection. The pulse controller signal is measured in milliseconds, and the pulse valve opens to generate a powerful impact airflow for a moment. Blowing. The input end (IN) of the right angle electromagnetic pulse valve is connected with the metal tube of the gas storage cylinder, and the output end thereof is connected with the spray pipe of the dust box, and the connecting thread is filled with the Teflon raw material tape to be tightly sealed.



    The right angle electromagnetic pulse valve is the actuator and key component of the pulse jet cleaning system. The diaphragm inside the valve divides the electromagnetic pulse valve into two front and rear air chambers. When the compressed air is turned on, it enters the rear air chamber through the orifice. At this time, the rear air chamber pressure closes the diaphragm to the output port of the valve, and the electromagnetic pulse valve is in the "closed" state. The electric signal of the pulse blowing control device moves the armature of the electromagnetic pulse valve, the vent hole of the air chamber is opened, the air chamber is quickly robbed, the diaphragm moves backward, the compressed air is blown through the valve outlet, and the pulse valve is "opened". The compressed air is instantaneously ejected from the valve to form a blowing air stream.



    The length of the injection cycle of the right angle electromagnetic pulse valve directly affects the pressure drop of the precipitator. For the pulse bag type dust collector with timing control, after the injection cycle is set, it is periodically blown (ie, the pulse controller is turned on). By adjusting the pulse period, the dust collector can be operated with the pressure drop substantially stable. The blowing cycle should be extended as much as possible without affecting the normal operation of the precipitator. Right angle electromagnetic pulse valve reliability:



    1. Work system: divided into long-term work system, repeated short-time work system and short-term work system. Our conventional products are long-term work, that is, the coil allows long-term power-on work. For long-time valve opening only when the time is closed, the normally open solenoid valve should be used. When used in short-time work and large batch sizes, special orders can be made to reduce power consumption.



    2. Working frequency: When the operating frequency is high, the structure should give priority to the direct-acting solenoid valve.



    Welcome to your inquiry!
