4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material

4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material

    • 4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material
    • 4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material
    • 4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material
    • 4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material
  • 4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: BB08023502

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pieces
    Price: negotiation
    Packaging Details: Inner Box, Carton, Pallet
    Delivery Time: 7- 10 days
    Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
    Supply Ability: 300000 pieces per month
    Contact Now
    Detailed Product Description
    Type: Coils, Accessories Material: Plastic, Brass
    Product Name: Pneumatic Solenoid Valve Coils Voltage: DC12V/DC24V/AC110V/AC220V
    Power: AC:5VA DC:2.8W Color: Black (Other Color Can Be Customized)
    Application: 4V Series Pneumatic Solenoid Valve Accessories Insulation Class: H, B, F
    Connection Type: Lead-type

    φ8 Diameter 4V110 Series Solenoid Coils With Flying Leads AC220V/AC110V/DC24V/DC12V



    There are many problems to be paid attention to during 4V110 series solenoid coil transportation process. The following is a detailed introduction for you:


    1. Protection working

    Pay attention to the protection of the electromagnetic coil products. For example, the electromagnetic coil without the junction box is sheathed on the pins or packaged with the blister tray. If it is a solenoid valve, it needs a single package. Generally, we need to Different coils are packaged in a way that fits the shape of the product, which protects our products from loss during transportation.



    2.Stacking processing

    Electromagnetic coil transportation needs to pay attention to the stacking problem. Many manufacturers will load too many products on the vehicle in order to save transportation costs. This stacking treatment has great safety hazards and will have an impact on product performance.



    Our company is very careful on the packaging to ensure the integrity of the product transportation.



    Techincal paramter of φ8 mm diameter Lead-Type 4V110 Series Solenoid Coils:

    Product model BB08023502
    Normal voltage AC220V/AC110V/DC24V/DC12V
    Normal power AC:5VA DC:2.8W
    Insulation class H, B, F
    Connection type Lead-type
    Applicability 4V series pneumatic solenoid coils
    Weight 29.5 g



    Main dimension of 4V series pneumatic solenoid coils AC220V/AC110V/DC24V/DC12V:

    4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material



    Automated winding production of 4V100 series electromagnetic valve coils:

    4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material



    4V120 series double lead type coils electric solenoid valves:

    4V110 Series Valve Solenoid Coil With Flying Leads φ8 Diameter Plastic / Brass Material



    How to install the solenoid valve coils:

    1. Check if the solenoid valve and the selected parameters are consistent, such as voltage, resistance, pressure, etc. If the error occurs, the solenoid valve coil will be burnt out or the solenoid valve will not work properly.



    2. Before cleaning the pipeline, it is necessary to confirm the cleanliness of the medium. If the medium is not clean and the impurities enter the solenoid valve, the pilot head will be stuck and the solenoid valve will not work or even the electromagnetic coil will be burned. In order to prevent this, the pipeline is in the pipeline. The filter should be installed or air source installed.



    3. Install the solenoid valve coil of the solenoid valve vertically on the horizontal and ground pipes. If it is in special circumstances, it cannot be installed vertically. The appropriate solenoid valve should be customized in advance, otherwise the diaphragm of the solenoid valve will be stuck. Can not work normally.



    4. When installing, add a safety process and install a manual cutting valve to facilitate maintenance in case of failure.



    5, pay attention to the direction of installation, can not be reversed, according to the direction indicated on the package, in some special circumstances such as vacuum can be reversed.



    6. If the water may appear in the medium, you must take appropriate protective measures or choose a solenoid valve with a waterproof hammer function.



    Welcome to your inquiry!
