Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve

Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve

    • Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve
    • Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve
    • Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve
    • Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve
  • Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: ISO、CE
    Model Number: A62

    Payment & Shipping Terms:

    Minimum Order Quantity: 3 pc
    Price: negotiation
    Packaging Details: PVC bag, inner box, carton, than packed by pallet
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Material: Rubber Application: Industrial
    Working Pressure: 0.2~0.6MPa Color: Black
    Size: 2 1/2'' Media: Air

    Black Rubber Replacement Repair Kit Diaphragm A62 for ASCO 2 1/2 Pulse Valve

    We stock and supply most brand name solenoid or pilot valves and enclosures including the following brands:ASCO type,Goyen type and SBFEC type,etc.We also offer lower cost alternatives on our own line of industrial Dust Collector Valves and Fittings.

    Same day shipping is available on a huge selection of solenoid valves and enclosures in a variety of AC and DC voltages and electrical configurations including flying leads, conduit, screw, spade and DIN connections. Solenoid repair kits are also available.

    Not only Pulse Valve Diaphragm,but also Solenoid Coil,Armature and Sealing,etc.

    We guarantee every product is seriuously controled in their process of producing and testing.We used suprior material at a fantastic price.You can be rest assured of our products quality and prices.



    Model 2 1/2" pulse valve rubber diaphragm
    Center distance φ145.5
    Outer diameter /
    Hole numbers for mounting 6
    Working ambient temperature -20℃ ~ 80 ℃
    Working pressure 0.2Mpa ~ 0.6Mpa
    Working medium Water/Clean air
    Life expectancy over 1 million times or 2 yeas
    Quality Certification CE,ISO



    The drawings of ASCO type Diaphragm A62 indicate center distance φ145.5

    Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve



    Refer to Pulse Valve Accessories,not only Diaphragm,also includes Armature/Spring/Sealing element etc

    Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve       Black Rubber Replacement Solenoid Valve Diaphragm A62 For ASCO 2 1/2 Pulse Valve




    The effect of electromagnetic pulse valve diaphragm quality on service life:
    The electromagnetic pulse valve diaphragm invalidates the whole dust collector: because the diaphragm of one valve is broken, the pressure of the whole air bag is greatly reduced and the air volume is insufficient, so that other valves on the air bag can not be properly blown, and the dust cleaning of the dust collector is bad. Partial paste bag phenomenon, the dust ratio of the dust collector is increased, the running resistance is increased, and the working life of the filter material is accelerated.

    Electromagnetic pulse valve diaphragm increases equipment maintenance and maintenance difficulty: When a small part of the valve diaphragm breaks, it is difficult for the field staff to judge the cause of the malfunction. It is necessary to find a valve in which the diaphragm is broken in hundreds of valves, and it takes a lot of time to inspect the valves one by one.

    The electromagnetic pulse valve diaphragm seriously affects the production operation:
    When the valve fails, it is often necessary to stop the entire filter box or rely on the bypass exhaust method to carry out maintenance work, and sometimes even stop the entire dust removal system or even the entire production line for accident repair, seriously affecting the normal production of the enterprise, pollution site Industrial environment. Frequent failure of the dust removal system may also result in the company being punished by local environmental law enforcement agencies, fined or even stopped or closed.



    If you want to know something more,pls feel free to contact us
