Electromagnetic Diaphragm A40 for ASCO type Dust Pulse Valve SCG353A047 Application in Industry Filter

Product Details:

Place of Origin:	China
Brand Name:	OEM
Certification:	ISO、CE
Model Number:	A40

Payment & Shipping Terms:

Minimum Order Quantity:	3 pc
Price:	negotiation
Packaging Details:	pp bag inside, carton box outside
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Material:	NBR	Media:	Air
Pressure:	0.2MPa~0.6MPa	Port Size:	1 1/2''
Type:	Dust Pulse Valve	Color:	Black
High Light:	ASCO Diaphragm , ASCO Pulse Valve Diaphragm , ASCO Membrane

Electromagnetic Diaphragm A40 for ASCO type Dust Pulse Valve SCG353A047 Application in Industry Filter

The solenoid valve diaphragm is also called the pulse valve diaphragm. The pulse valve diaphragm is a rivet head for sealing the air outlet of the compressed air pipeline or the plugging valve. The venting relief hole and the bolts for fixing the surrounding are used. a whole piece of high-quality rubber diaphragm formed by the hole, which is in the electromagnetic pulse valveKey control components. The pulse valve diaphragm is one of the "opening" of the blowing air circuit of the pulse bag type dust collector cleaning system and the normal operation of the valve body.
The quality of the pulse valve diaphragm directly affects the working stability of the pulse bag type dust collector cleaning system, and is also directly related to the use cost of the dust removal device. The general pulse valve diaphragm has a promise of service life or number of actions. High quality pulse valve diaphragm can be directly reducedThe cost of using dust removal equipment.

Model	1 1/2" pulse valve diaphragm
Center distance	φ116.5
Outer diameter	/
Hole numbers for mounting	6
Working ambient temperature	-20℃ to 80 ℃
Working pressure	0.2Mpa to 0.6Mpa
Working medium	Water/Clean air
Life expectancy	over 1 million times or 2 yeas

The actual drawings of ASCO type Diaphragm A40


Almost pulse valve diaphragm installation in bag dust filtration system


Actual Certificate of Origin for your perusal


The role of the solenoid valve diaphragm in the dust collector:
that is, the size of the oil pressure in the control oil passage is generally installed in the main oil passage or the damper back pressure oil passage to reduce the oil pressure shock when the shifting and the lock are unlocked. Keep the device running smoothly. Our pulse solenoid valve diaphragm is the most
It is suitable for the production of high-quality rubber sheet for pulse valve diaphragm. It has strong oil resistance, acid resistance, high temperature resistance and alkali resistance. It can easily ensure complete synchronization with other control components and control the injection of pulse compressed air.

Application of Pulse Valve Diaphragm:

The electromagnetic pulse valve diaphragm is the diaphragm in the electromagnetic pulse valve body, which is the key to its normal operation. The electromagnetic pulse valve is the blowing air circuit switch of the pulse bag type dust collector cleaning system.

Since the pulse valve diaphragm is a flexible mechanism that requires frequent opening and closing operations to control air circulation, and requires good flexibility, and requires as high a sealing as possible, the material of the pulse valve diaphragm is directly It is related to the service life and effect of the pulse valve diaphragm.

In other words, the quality of the pulse valve diaphragm directly affects the working stability of the pulse bag type dust collector cleaning system, and is also directly related to the use cost of the dust removal device. The pulse valve diaphragm has a promise of service life or number of movements. The use of a high-quality pulse valve diaphragm can directly reduce the cost of dust removal equipment.

For more information,please feel free to contact us!
