1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass

1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass

    • 1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass
    • 1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass
    • 1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass
    • 1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass
  • 1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: ISO、CE
    Model Number: 2W025-08

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: USD2.00-10.00 per pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union, T/T
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Media: Water,Gas,Oil,air Power: Pneumatic
    Port Size: 1/4'' Material: Brass
    Color: Golden Yellow Structure: Control

    1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass



    About Voltage selection:
    1. Standard Voltage: DC24V; 110V AC/50hz, 220V AC/50HZ; 110V AC/60HZ, 220V AC/60HZ
    2. Also have DC12V and other voltages. but DC12V power is weak, so fluid pressure is lower than other voltages
    Valves' installation:
    Fluid flow direction must follow the flow arrow marked on valve body.
    Installation: must be horizontal position.
    Fluid pressure: working under the valves requirements.
    Fluid requirement: clean without impurity.

    Model No. 2W025-08
    Working Medium Air,Water,Oil,Gas
    Motion Pattern Direct Drive Type
    Type Normal Close Type
    Aperture of Flow Rate 2.5
    Joint Pipe Bore 1/4”
    Operating Temperature Rang -5~80
    Voltage Range ±10%
    Operation Fluid Viscosity 20 CST(below)
    Working Pressure(kgf/cm Gas:0~7, Oil:0~5, Air:0~7, Water:0~5
    Material of Oil Seal NBR,EPDM Or Viton

    Outlook picture of 2W025-08

    1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass

    Drawings of 2W025-08

    1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass

    Sample of valve body

    1/4'' Inch Golden Yellow Color 2V Water Control Valve 2W025-08 made of Superior Brass



    The Electromagnetic Valve Fault and Eliminate:
    electromagnetic valve does not work after the power supply:
    1, check the power supply wiring whether bad -)

    connectors and wiring connection again;
    2, check whether the power supply voltage in the plus or minus working range --) to switch to normal position;
    3, whether the ring

    sealing off -) to welding;
    4, coil short circuit, replace the coil;
    5, differential pressure is not appropriate to work -) -) or replacement of proportion adjustment pressure

    difference electromagnetic valve;
    6, fluid temperature is too high -) change of proportion of electromagnetic valve;
    7, have impurities to make electromagnetic valve of the

    main valve core and the moving core card die -) cleaning, such as seal damage the seal and install the filter should be changed;
    8, the liquid viscosity is too large, high

    frequency and life expectancy has to -) replacement products.

    (2) the solenoid valves can't shut down:
    1, the main valve core or moving iron core of seal is damaged, replace the seal;
    2, fluid temperature, viscosity is too high -) change

    of the electromagnetic valve;
    3, have impurities into the solenoid valve core or moving iron core -) for cleaning;
    Four, spring life have to or replace the spring deformation
    5, orifice balance hole jam --) timely cleaning;
    6, working frequency is too high, or life has to -) election products or replacement products.
    (3) other situations:
    1.internal leakage, check whether the seal is damaged, the spring is bad assembly.
    2, outside leakage -) joint looseness or seal has bad -) screw or replace the seal;
    3.electricity from time to tome noise -) leader on fasteners loose, tighten. Voltage fluctuation is not allowed within the scope of adjust voltage. Core surface impurities or

    uneven absorption, clean or replace in a timely manner



    Any question will be answered at once,If you have the current or future demand,plz contact us without any hesitation!
