DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants

DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants

    • DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants
    • DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants
    • DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants
    • DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants
  • DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants

    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: GB,CE
    Model Number: MSV-1064/3

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Pallet,Cartons ,Boxes
    Delivery Time: About one week
    Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
    Supply Ability: 4800 sets per month
    Contact Now
    Detailed Product Description
    Port Size: 3/8'' Inches SAE Material: Brass
    Power: Solenoid Temperature Of Media: -35°C-105°C
    Position: Liquid Line In Refrigeration System Structure: Diaphragm
    Pressure: 0.5-25 Bar Media: Refrigerant
    Voltage: 110VAC,220VAC,AC380V,12VDC,DC24V Refrigerant: HCFC/HFC/CFC(customer Specified)

    DC24V MSV 1064/3 3/8'' SAE Inch Refrigeration Solenoid Valve For Liquid Line With Refrigerants



    Everyone knows the birth of a refrigeration device. It is a combination of many components that needs to be done. When we first learned about the refrigeration equipment, we have already occupied the four core originals in the refrigeration equipment. The four core components are important, but there is also an accessory that is also playing an important role in accessibility. This is MSV-1064/3 hot gas line solenoid valve for refrigeration, an automatically controlled valve that controls the flow of the entire system to achieve temperature control.



    At present, we often use a variety of refrigeration equipment in our work and life, such as: air-cooled screw chiller, water-cooled screw chiller, water-cooled modular industrial chiller, water-cooled chiller, etc. The series of products are widely used in our industrial production, large shopping malls, hotels, apartments and other places. It is a product that many industries need to purchase.Therefore, the demand and supply of high quality MSV1064/3 refrigeration solenoid valves are also increasing.



    Technical information of MSV 1064/3 G3/8'' solenoid valve for refrigeration system:

    Model Numbers

    Connection sizes

    (SAE/ODF two types)

    Main Dimension

    KV values

    (m³/h)

    H1 H2 L1 Q
    Inch mm Inch mm Inch mm Inch mm
    MSV-1020/2 1/4''SAE 3.0 75 2.5 62.5 2.3 58     0.175
    MSV-1020/3 3/8''SAE 3.0 75 2.5 62.5 2.6 65     0.23
    MSV-1028/2 1/4''ODF 3.0 75 2.5 32.5 4.9 125     0.15
    MSV-1028/3 3/8''ODF 3.0 75 2.5 62.5 4.9 125     0.23
    MSV-1064/3 3/8''SAE 3.2 82 2.7 69.5 2.6 68     0.8
    MSV-1064/4 1/2''SAE 3.2 82 2.7 69.5 2.8 72     0.8
    MSV-1068/3 3/8''ODF 3.2 82 2.7 69.5 4.5 111     0.8
    MSV-1068/4 1/2''ODF 3.2 82 2.7 69.5 5.0 127     0.8
    MSV-1070/4 1/2''SAE 3.6 91 3.0 75.0 3.9 100 1.8 45 2.2
    MSV-1070/5 5/8''SAE 3.6 91 3.0 75.0 4.2 106 1.8 45 2.61
    MSV-1078/4 1/2''ODF 3.6 91 3.0 75.0 5.0 127 1.8 45 2.2
    MSV-1078/5 5/8''ODF 3.6 91 3.0 75.0 6.9 173 1.8 45 2.61
    MSV-1078/6 3/4''ODF 3.7 96 3.0 75.0 7.0 179 1.8 45
    MSV-1078/9 1 1/8''ODF 4.5 115 3.8 96.0 9.8 250 3.1 80 10
    MSV-1078/11 1 3/8''ODF 6.8 172 5.4 138.0 10.9 278 2.8 68 16
    MSV-1090/5 5/8''SAE 4.2 106 3.0 78.0 1.7 120 2.2 57 3.8
    MSV-1090/6 3/4''SAE 4.2 106 3.0 78.0 4.9 124 2.2 57 4.8
    MSV-1079/7 7/8''ODF 3.6 91 3.0 75.0 7.5 190 1.8 45 2.61
    MSV-1079/11 1 3/8''ODF 4.5 115 3.8 96.0 11.5 292 3.1 80 10
    MSV-1079/13 1 5/8''ODF 6.8 172 5.4 138.0 10.9 278 2.8 68 16
    MSV-1098/7 7/8''ODF 4.2 106 3.0 78.0 7.1 180 2.2 57 5.7
    MSV-1099/9 1 1/8''ODF 4.2 106 3.0 78.0 8.5 216 2.2 57 5.7
    MSV1099/11 1 3/8''ODF 6.2 157 5.0 127.0 10.9 291 2.8 68 10



    Overall dimension of AC220 V DC24V MSV-1064/3 HVAC solenoid valve in low temperature:

    DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants



    Unit Cooler Used MSV type 1064/3 refrigeration solenoid valve to control the refrigerants:

    DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants



    Packing and delivery of MSV series 1064/3 solenoid valv for Liquid line in refrigeration system:

    DC24V MSV 1064/3 Refrigeration Solenoid Valve For Liquid Line With Refrigerants



    Preservation cabinet with MSV-1064/3 refrigeration solenoid valve:

    At present, the fruit fresh-keeping cabinets on the market can be divided into air-cooled open-type fresh-keeping cabinets and direct-cooled glass-door fresh-keeping cabinets. The refrigeration principle is operated by a compressor, allowing internal refrigerant to circulate, condenser heat absorption, and evaporator refrigeration to form. Air conditioning. Let the bacteria inside the food slow down the activity and play a role in extending the shelf life. This supermarket fruit storage cabinet can also store vegetables, drinks and so on.



    Preservation cabinet structure

    The fresh-keeping cabinet is a cabinet for storing food and refrigerated food. It has a cabinet for refrigerating and preserving, which not only improves the grade of the store, but also prolongs the life of the food. Which accessories are the fresh-keeping cabinets made up of?



    First, the material: galvanized sheet, plastic profiles, lamps, back plug-in power supply, polyurethane foam board, top mirror, two side baffle glass, thermostat, compressor, curtain



    Second, the thermostat.


    Third, the built-in compressor, the compressor of the external machine.


    Fourth, the base: the base of the one machine is generally 60cm high, because the one machine compressor is to be placed inside the base, so it must be higher; and the base of the split machine is generally 35cm high, the split machine is with the home air conditioner is The same principle, the compressor should be placed on the outside wall, so the base does not have to be done too high, so the use space of the freezer is relatively larger.


    Fifth, Air outlet design: The air outlet form of the fresh-keeping cabinet is to cover the corners of the air curtain cabinet with cold air blown from the back and the top of the air directly to achieve the preservation of food or fruit.



    Welcome to your inquiry!
