    Detailed Product Description
    Material: Aluminum Alloy Structure: Control
    Type: Five-position Two-way Solenoid Valve Working Pressure: 0.15-0.8MPa
    Power: Pneumatic,Solenoid Motion Pattern: Internally Pilot-actuated

    Five-Position Two-Way Solenoid Pneumatic Valve Internally Pilot-actuated Wiring Form 4V110-06



    Pneumatic valves are valves that are driven by compressed air. When purchasing pneumatic valves, only the specifications, categories and working pressures can meet the procurement requirements. They can be used to control various types of fluids such as air, water, steam, various corrosive media, mud, oil, liquid metal and radioactive media. flow. It is not perfect in the current market economy environment. Because pneumatic valve manufacturers compete for products, they each carry out different innovations under the concept of unified design of pneumatic valves, forming their own corporate standards and product personality. Therefore, in the procurement of pneumatic valves, the technical requirements are more detailed, and it is necessary to coordinate with the manufacturers to obtain a consensus. As an accessory to the pneumatic valve procurement contract, it is very necessary. This type of valve should generally be installed horizontally in the pipeline.







      4V210-08
    Model
    Position and way NO. 2/5 way
    Effective area 14mm2(CV=0.78)
    Port size Air inlet=Air outlet=G1/8''
    Fluid 40 micron filtered air
    Operation Inside pilot type
    Operating pressure 0.15~0.8MPa
    Max.proof pressure 1.2MPa
    Temperature 5~50 C
    Allowable boltage ±10% of rated voltage
    Power consumption AC:2.5VA DC:2.5W
    Coil insulation &protection grade Class F.IP65
    Electrical entry connector
    Highest action frequency 5 cycle/second
    Shortest excitation time 0.05 second
    Voltage DC 12V 24V AC 110V 220V
    Package 1 x solenoid valve





    4V110-06 5 Way 2 Position Solenoid Valve Internally Pilot Actuated Wiring Form



    4V110-06 5 Way 2 Position Solenoid Valve Internally Pilot Actuated Wiring Form





    The Working Priciple of 4V110-06:

    The compressed air is used to push the movement of multiple sets of combined pneumatic pistons in the actuator, and the characteristics of the beam and the inner curved track are transmitted to drive the hollow core spindle to rotate, and the compressed air disk is sent to each cylinder to change the position of the inlet and outlet to change the spindle rotation. Direction, according to the required torque of the load (valve), the number of cylinder combinations can be adjusted to drive the load (valve). Two-position five-way solenoid valves are usually used with double-acting pneumatic actuators. Two positions are controllable: on-off, five-way is five-channel ventilation, one of which is connected to the air supply, two and two The inlet and outlet ports of the external air chamber of the cylinder are connected, and the two are connected with the inlet and outlet ports of the internal air chamber. The specific working principle can refer to the working principle of the double-acting pneumatic actuator.



    Commom Request

    1. The specifications and categories of pneumatic valves produced shall meet the requirements of pipeline design documents.

    2, the pneumatic valve model should be marked according to the national standard number requirements. If the enterprise standard, should indicate the relevant description of the model.

    3, pneumatic valve working pressure, requirements pipeline working pressure, on the premise of not affecting the price, the valve can withstand the pressure should be greater than the actual pipeline pressure; Under the closed condition of pneumatic valve, any side should be able to withstand 1.1 times of valve pressure without leakage; When the valve is open, the valve body should be able to withstand twice the working pressure of the valve.

    4, pneumatic valve manufacturing standards, should be described according to the national standard number, if the enterprise standards, the procurement contract should be attached to the enterprise documents.
