Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves

Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves

    • Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves
    • Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves
    • Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves
    • Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves
  • Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves

    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: ISO
    Model Number: DMF-Z-62S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: negotiation
    Packaging Details: Box,Carton.
    Delivery Time: 3-5 Work Days
    Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
    Supply Ability: 7000 pcs per month
    Contact Now
    Detailed Product Description
    Port Size: 2-1/2" Material: Alloy
    Temperature Of Media: Normal Temperature Voltage: DC24V,AC220V,AC110V
    Working Pressure: 0.3-0.8MPa Fluid: Air

    Alloy 2 1/2 Inch Pulse Valve /AC220V Bag Filter Dust Collector Valves DMF-Z-62S



    DMF-Z-62S is a right angle pulse valve with double diaphragm, practical and reliable, more durable.The angle between the inlet and outlet is 90°, which is suitable for the installation and connection of air bag and dust collector blow pipe.of course, if you need other types of single diaphragm pulse valve, we can also provide.



    Advantage

    1.Small fluid resistance

    2.Opening and closing is more labor-saving

    3.Unlimited media flow

    4.Simple shape,Wide range of applications



    Specification

    Working medium: clean air

    Voltage: DC24v AC110v AC220v (optional)

    Service life: 1 million times 2-3 years

    Ambient Temperature:-5-50℃

    Body:Aluminum ADC12

    Spring:Stainless Steel

    Screws:Stainless Steel



    Order code

    Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves



    Dimension Drawing of DMF-Z-62S

    Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves



    Number Kv/Cv Blowing Area Port Size Weight Packing Dimension
    DMF-Z-62S 129.26/150.85 27-38 G2 1/2" 3.2 20.4x18.8x23cm



    More Details

    Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves

    Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves

    Alloy 2 1/2 Inch Pulse Jet Valves / AC220V Bag Filter Dust Collector Valves



    How to choose a suitable electromagnetic pulse valve

    Pipe parameters: select the diameter specification and interface mode
    1. Path size: the diameter of the pipe should be determined by the inner diameter or flow requirement of the pipe.
    2. Interface mode: For internal thread, external thread, flange interface, etc., select the applicable specifications.



    Fluid parameters: select material and temperature resistance
    1. Corrosive fluids: chemical interactions between certain metals and specific corrosive liquids
    2. High temperature fluids: Some fluids have a higher temperature than the melting point of the metal, causing changes in their physical form.
    3. Fluid state: It mainly prevents the leakage of toxic and harmful gases and fluids. Just keep it airtight
    4. Fluid viscosity: the viscosity of the fluid to the metal is different.



    Pressure parameters: selection principle and structural variety
    1. Nominal pressure: reference value related to the pressure resistance of piping system components
    2. Working pressure: reference value of pressure resistance of piping system components in product working condition



    please care the products details at our website, any confuse please contact us or Note your request online. Big quantity purchase ,please contact our online service to ask more economic shipping way or discuss the more pretty price.



    Wait your inquiry!
