ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060

ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060

    • ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060
    • ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060
    • ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060
    • ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060
  • ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: CE、ISO
    Model Number: SCXE353.060

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: negotiation
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Material: Aluminum Alloy Connection: Thread
    Power: Pneumatic Structure: Angle
    Size: 3'' Type: Two-position Two-way Solenoid Valve

    ASCO type 353Series 3 Inch Submerged Pulse Valve SCXE353.060



    The Asco pulse valve has through holes at different positions. Each hole is connected with a different oil pipe. The middle of the cavity is a piston. On both sides are two electromagnets. Which side of the magnet coil is energized to the valve body, which is attracted to the control valve. The movement of the body to open or close different oil drain holes, and the oil inlet hole is normally open, the hydraulic oil will enter different oil drain pipes, and then the pressure of the oil pushes the piston of the oil cylinder, and the piston drives the piston rod and the piston again. The rod drives the mechanical device. This controls the mechanical motion by controlling the current through and off of the electromagnet.





    SCXE353.060 Valve Body Aluminium
    Stem SS304
    Inner Moving Core 430FR
    Spring SS304
    Seal and Diphragm Plate NBR
    Diaphragm Neoprene
    Solenoid Coil Enameled Copper Wire
    Solenod Coil Insualtion Glass F
    Connector of SCXE353.060 Solenoid Coil PG11P
    Standard ISO4400
    Electrical Safty Standard IEC335





    ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060



    ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060

    ASCO Type Dust Collector Valve / 3 Inch Submerged Pulse Solenoid Valve SCXE353.060


    The ASCO pulse dust valve consists of two basic functional units: an electromagnetic coil and a magnetic core. A valve body containing one or several holes. When the electric coil is energized or de-energized, operation of the core will cause fluid to pass through the valve body or be severed. The solenoid is mounted directly on the valve body and the core is enclosed in a sealed tube to form a compact, compact combination.



    What should you do when cause damage:

    1. The spring is damaged. The spring on the pulse valve spool is easily damaged. The appearance is that the pulse valve is deflated to the blow port for a long time. The treatment method is to replace the spring.
    2. The rubber pad is damaged. After the use time is long, the rubber pad on the pulse valve spool is easily damaged. The appearance is that the pulse valve is deflated to the blowing port for a long time. The treatment method is to replace the rubber pad.
    3, the valve core dirt, because the intake air is not clean, causing the fouling of the valve core, resulting in the appearance of long-term intake of the nozzle or the pulse valve does not work after the power, the treatment method is to clean the valve core.
    4, the diaphragm is damaged, after long-term work, the diaphragm is easy to fatigue, oxidation, etc., resulting in the appearance of long-term deflation of the pressure relief port, the pulse valve does not work, the treatment is to replace the diaphragm.
    5. The orifice is blocked or damaged. The intake air is not clean and the throttle hole is blocked. The appearance is that the pulse valve is deflated to the nozzle for a long time. The treatment method is to clean the orifice; the orifice is damaged or missing, and the orifice is made. Loss of interception, resulting in abnormal pressure relief, the appearance is that the pulse valve has action after the power is turned on, the pressure relief port is deflated, but the pulse valve is not sprayed, the treatment method is to replace the orifice
