24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve

24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve

    • 24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve
    • 24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve
    • 24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve
    • 24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve
  • 24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve

    Product Details:

    Place of Origin: CHINA
    Brand Name: Brando
    Certification: CE
    Model Number: EVR6-038S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: $25-$43 per set
    Packaging Details: Inner Box,Carton,Pallet
    Delivery Time: 4-9 days
    Payment Terms: L/C, T/T, Western Union,Paypal
    Supply Ability: 4550 sets per month
    Contact Now
    Detailed Product Description
    Material: Pure Brass Temperature Of Media: -40°C-105°C
    Port Size: 1/4"-2 1/8" Power: Solenoid Coil And Armature
    Pressure: Medium Pressure Application: Industrial Chiller Refrigeration System
    Structure: Armature, Spring, Valve Body, Solenoid Coil Connection: Threaded
    Type: Normally Close Medium: All Fluorinated Refrigerant

    24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve



    EVR6-038S chiller refrigeration solenoid valve is a normally closed two-way piloted valve, usually used for liquid refrigerant or exhaust air, water or compressed air. Our products can replace similar products, such as DANFOSS, CASTEL.The nut system with o-ring ensures water tightness.The carefully designed coil winding can maintain normal operation under extreme conditions.The EVR series cooling refrigeration solenoid valve is a one-time or two-open solenoid valve for one-way flow. Used in liquid, suction and hot gas lines for refrigeration, refrigeration and air conditioning units. A wide range of voltage coils are available, while the valve body is versatile.



    Technical data of DC24V EVR6-038S freezer refrigeration solenoid valves:

    Model number: Connections: H1 H2 H4 L L2

    KV value

    (m³/h)

    SAE inlet/outlet ODF inlet/outlet (Solder) Inch mm Inch mm Inch mm Inch mm Inch mm Inch mm
    EVR3-014 EVR3-014S 1/4 6 0.5 14 2.8 71 - - 4.0 102 0.3 7 0.27
    EVR3-038 EVR3-038S 3/8 10 0.5 14 2.9 73 - - 4.6 117 0.4 10
    EVR6-038 EVR6-038S 3/8 10 0.5 14 3.1 79 - - 4.4 111 0.4 10 0.8
    EVR6-012 EVR6-012S 1/2 12.8 0.5 14 3.1 79 - - 5.0 127 0.4 10
    EVR10-012 EVR10-012S 1/2 12.8 0.6 16 3.1 79 - - 5.0 127 0.4 10 1.9
    EVR10-058 EVR10-058S 5/8 16 0.6 16 3.1 79 - - 6.3 160 0.5 12
      EVR15-058S 5/8 16 0.7 19 3.4 86 - - 6.9 176 0.5 12 2.6
      EVR15-078S 7/8 22 0.7 19 3.4 86 - - 6.9 176 0.7 17
      EVR20-078S 7/8 22 0.8 20 3.5 90 - - 7.5 191 0.7 17 5
      EVR20-118S 1 1/8 28.8 0.8 20 3.5 90 - - 8.4 214 0.8 22
      EVR22-138S 1 3/8 35 0.8 20 3.5 90 - - 11.1 281 1 25 6
      EVR25-118S 1 1/8 28.8 1.5 38 5.4 138 2.8 72 10.0 256 0.8 22 10
      EVR25-138S 1 3/8 35 1.5 38 5.4 138 2.8 72 11.0 281 1 25
      EVR32-138S 1 3/8 35 1.9 47 4.4 111 2.1 53 11.0 281 1 25 16
      EVR32-158S 1 5/8 42 1.9 47 4.4 111 2.1 53 11.0 281 1.1 29
      EVR40-158S 1 5/8 42 1.9 47 4.4 111 2.1 53 11.0 281 1.1 29 25
      EVR40-218S 2 1/8 54 1.9 47 4.4 111 2.1 53 11.0 281 1.3 34



    Normal close vs Normal open 220V AC EVR6-038S cooling solenoid valves in refrigeration system:

    24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve



    Liquid injection kits with EVR6-038S 3/8'' inch thread port brass cooler solenoid valves:

    24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve



    EVR6-038S chiller refrigeration eletromagnetic valves application:

    24Voltage DC G3/8'' Inch Threaded EVR6-038S Chiller Refrigeration Solenoid Valve



    Types of compressor with EVR6 ice maker refrigeration solenoid valves:


    In the refrigerating machine system, the compressor is the power to ensure refrigeration, the compressor is used to increase the refrigerant pressure in the system, so that the refrigerant circulation in the refrigeration system, to achieve the purpose of refrigeration. Compressors can be divided into three types according to their structure: open type, semi-closed type and fully closed type. At present, most of industrial cold water machine the cold water machine for more than 0 ℃ cold water machine adopts closed compressor. Cold water temperature is below 0 ° C temperature chiller use semi-hermetic compressor (usually equipped with a screw and reciprocating compressor). The open type refrigerator is generally used in the refrigeration system with ammonia as the refrigerant.



    A fully enclosed refrigeration compressor is a device that places the compressor and the motor in a sealed iron case. From the outside can only see the compressor suction and exhaust pipe joint and motor wire; Compressor shell is divided into two parts. After the compressor and motor are installed, the upper and lower iron shells are welded together. It can't be disassembled normally, so the machine is reliable. In the enclosed refrigeration compressor, there are piston compressor and scroll compressor.


    The structure of the fully enclosed scroll refrigeration compressor is mainly composed of the following parts: Rotary inlet and outlet valves; Pressure gauge connection; Built-in overload protection; Elastic foundation; Crankcase heater; Built-in lubricating pump.



    The biggest advantages of scroll refrigeration compressor are :



    1. Simple structure: the compressor body only needs 2 parts (moving plate, fixed plate) can replace 15 parts of the piston compressor.



    2. High efficiency: the efficiency of the compressor can be improved by separating the gas and reducing the heat transfer between the suction and the processing.



    3. The vortex compression process and the transformation process are very quiet.
