Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment

Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment

    • Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment
    • Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment
    • Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment
    • Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment
  • Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: CE、ISO
    Model Number: SCG353A044

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: negotiation
    Packaging Details: PVC Bags,Boxes,Cartons,Pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Port Size: 1 Inch Power: Pneumatic
    Application: Industrial,Automation Equipment Type: Pneumatic Solenoid Valve
    Working Pressure: 0.2-0.6Mpa Body Material: Aluminum Alloy

    Black Color 1 Inch ASCO Type Solenoid Valve SCG353A043 for Industrial Equipment


    The solenoid valve consists of two basic functional units: The solenoid and the core contain one or several holes. When the coil is energized or de-energized, the operation of the core will cause fluid to pass through the valve body or be cut off. The coil is mounted directly on the valve body and the core is enclosed in a sealed tube to form a compact, compact combination.


    Detailed Date of Pulse Valve SCG353A044:

    Construction
    Body Aluminum
    Core Spring Stainless steel
    Sealing &disc NBR(nitrile/buna-n)
    Diaphragm TPE(hytrel)
    Shading coil Copper
    Voltage DC: 24V, AC:24V,48V,110V,230V,Customized
    Working Temperature -5 to 55°C
    Protection Class IP65
    Working Pressure 0.2-0.6Mpa


    The Item(SCG353A044) Drawings for reference:

    Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment



    Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment

    We have advanced equipment



    Black Color 1 Inch Pneumatic Solenoid Valve SCG353A043 For Industrial Equipment



    The Operating Principle of SCG353A044:
    The structure is mainly composed of a pilot valve and a main valve, and the main valve adopts a rubber sealing structure. When the position is normal, the movable iron core seals the pilot valve port, the pressure in the valve chamber is balanced, and the main valve port seals the valve. When the coil is energized, electromagnetic force is generated to attract the movable iron core, and the medium in the main valve chamber is leaked from the pilot valve port, so that a pressure difference is generated, the diaphragm or the valve cup is quickly lifted, the main valve port is opened, and the valve is presented. The passage is gone. When the coil is de-energized, the magnetic field disappears, the movable iron core is reset, the pilot valve port is closed, and the pressure in the pilot valve and the main valve chamber is balanced, and the valve is closed again.



    Pulse Valve SCG353A044 Features:

    1, Two position, two way, normal close switch, magnetic solenoid water valve.
    2, Dust Collector Pulse Solenoid Valves
    3, Can be installed at any position, but it is a good choice when the horizontal tube keep upward.
    4, Used to control automatically the air in the pipeline.

    5.The upper limit of the fluid pressure range is high, it can be installed arbitrarily (customized), but the fluid pressure difference condition must be met.

    About Installation of the SCG353A044:

    1. The valves can be mounted in any position without affecting operation

    2. Threaded pipe connection is: G (ISO 228/1) or compression fitting

    3. For compression fitting types tightness is achieved by the compressed gasket on the blow tube

    4. The use of the rubber gaskets as sealing members will allow a slight misalignment in piping

    5. Other pipe threads are available on request

    6. Installation/maintenance instructions are included with each valve

    7. Spare Parts Kit and replacement coils are available





    If you have question, please contact us the first time.Thank you.
