3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color

3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color

    • 3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color
    • 3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color
    • 3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color
    • 3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color
  • 3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: ISO、CE
    Model Number: DMF-Z-76S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Pc/Pcs
    Price: negotiation
    Packaging Details: inner boxes,cartons,cases,pallets
    Delivery Time: one week after payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000Pcs/month
    Contact Now
    Detailed Product Description
    Certification: ISO、CE Color: Green
    ED: 100% IP: 65

    3.01KG Net Weight Green Color Z-Type Pulse jet Valve DMF-Z-76S G3'' pipe size ED 100%



    Right Angle electromagnetic pulse valve is the actuator and key component of the pulsed jet ash removal device, which can be divided into three types: right Angle type, submerged type and straight through type. The pulse valve is connected with the compressed air bag at one end and the spray pipe at the other end. The pulse valve back pressure chamber is connected with the control valve. The pulse controller controls the control valve and the pulse valve opening.



    When the controller has no signal output, the exhaust port of the control valve is closed, and the pulse valve nozzle is closed; When the controller sends a signal to control the vent is opened, the pulse valve back pressure gas discharge pressure reducing, outdoor produce pressure difference on both sides of diaphragm, diaphragm displacement due to the differential effect, injection pulse valve opens, the compressed air from the air bag, through the pulse valve by spray torch holes out (from the spray torch gas for a wind). Pulse valve life: standard installation, correct use, reasonable maintenance under the conditions of over 1 million cycles.





    Working pressure 0.-0.8MPa
    Using Life of Diaphragm Over 1 million Cycles
    Protection Class IP65
    Certification CE,ISO
    Material of Valve ADC12 Aluminum
    Blowing area 37-65㎡
    KV/CV 159.95/186.66
    Working Medium Clean,dry compressor air





    Drawings of DMF-Z-76S

    3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color



    We guarantee the products durable enough



    3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color



    Qulity must be seriously controled



    3.01KG Z - Type Pulse Jet Valve DMF-Z-76S G3'' Pipe Size ED 100% Green Color





    Working Principle:



    The electromagnetic pulse valve is composed of electromagnetic leader, diaphragm and valve body. The area of the back cavity of the diaphragm is larger than that of the front cavity.

    The electric controller input electric signal, make the electromagnetic leader absorb the moving column, open the unloading hole, the pressure gas in the back chamber of the diaphragm is discharged rapidly, the pressure gas in the front chamber of the diaphragm is lifted, the channel is opened, and the pulse valve is sprayed.

    When the electric pulse signal disappears, the spring of the electromagnetic leader immediately resets the moving column to close the unloading hole, and the pressure of the gas in the back chamber of the diaphragm and the force of the spring cause the diaphragm to close the channel and the valve to stop blowing. The damping hole on the diaphragm plays the role of damping airflow when the pilot head moving column lifts the gas pressure to unload. When the unloading hole is closed, the pressure gas is rapidly filled into the back cavity, making the diaphragm close the channel and stop blowing.





    Structure characteristics:



    Special nuts (made of aluminum alloy or stainless steel) and special sealing ring are used for inlet and outlet of right-angle pulse valve.

    The smooth inlet and exhaust pipe outer wall is sealed with valve body mouth end, which is simple in structure, convenient in operation and reliable in sealing. Pulse valve into

    The inner structure of the air port and the positioning steel ring can be installed and used to prevent loose due to inertial impact and ensure the accurate installation position

    Buy. Stainless steel nut in a long period of use, can still ensure convenient disassembly and assembly.
