Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V

Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V

    • Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V
    • Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V
    • Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V
    • Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V
  • Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V

    Product Details:

    Place of Origin: NINGBO CHINA
    Brand Name: Brando
    Certification: CE
    Model Number: 4V310-08

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Box,Carton,Pallet
    Delivery Time: 4-9 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 335000 pieces per month
    Contact Now
    Detailed Product Description
    Life Cycle: 10000000 Times Voltage: AC:24V 110V 220V 380V DC:12V 24V
    Piping Size: Air Inlet=Air Outlet=Exhaust=G 1/4'' Packing Dimension: 13.52x2.7x4cm
    Type: 5/2 Way Coil Number: Single Coil
    Material: Alloy, Aluminium Power: Solenoid, Pneumatic
    Structure: Control, Armature, Piston Operating Temperature: NBR For -5~80℃ And VITON For -5~150℃

    Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V



    The structure of the pilot type pneumatic solenoid valve is mainly composed of a valve body, a normally closed main valve flap, a normally open main valve flap, a pilot valve flap, an electromagnet and the like. The main valve flap and the piston are connected by a ram. The pilot type two-way solenoid valve is characterized by an internal spring-free elastic reset element, which completely switches the gas passages by aerodynamic force and electromagnetic force, and controls the normally open cavity and Normally closed chamber air supply and sealing. Structure in sliding column mode: good tightness and sensitive reaction. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life



    Internal piloted type pneumatic solenoid valve features: low power consumption, larger diameter, and a simple structure, arbitrary installation direction, but can only be used at both ends of the solenoid valve has a certain pressure difference occasions.



    Technical data of 4V310-08 air operated pneumatic solenoid valves:

    Model 4V310-08 4V320-08 4V330C-08 4V330E-08 4V330P-08
    Effective sectional area 25mm² 18mm²
    Position number two positions five ways three positions five ways
    Operating medium 40μm filtered air
    Action type Pilot piston actuated
    Wring form Lead wire or connector type
    Highest action frequency

    5 times per second



    Main Dimension of 5/2 way 4V310-08 single coil control pneumatic valves:





    Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V



    Structure diagram of G1/4'' connection size 4V310-08 electric magnetic valves:

    Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V

    DC24V/AC220V voltage solenoid coils for 4V310-08 electromagnetic valves:

    Airtac Type 5/2-Way 1/4'' 4V310-08 Pneumatic Single Solenoid Operated Valve DC24V/AC220V



    4V310-08 aluminum alloy body electromagnetic solenoid valve selection considerations:
    There are many types of solenoid valves, not only different brands, but also different models and types. Therefore, when selecting the type, it is necessary to select according to the specific needs, in order to maximize its performance. Then today, the first agent of imported solenoid valve dry ball automation and everyone talk about the selection of pneumatic solenoid valve.



    The conditions of the power supply should be taken into consideration, because they are divided into many different types depending on the voltage. Instead, select the appropriate voltage based on the specific installation environment and needs. Also note that some are for direct current, while others have AC power, so be sure to take into account the power supply conditions and choose the right model. This is also the most critical when selecting this equipment.



    Consider the environmental conditions to which the pneumatic solenoid valve is applied. In general, it is also the key to selection for the environment. Because the environment and temperature of different devices are very different. For example, if some humidity or rain will often be quiet, then you must choose a waterproof solenoid valve. If it is used in some high temperature environments, then the explosion-proof type should be selected, and if it is used in a corrosive environment, then the corrosion-resistant device should be selected.
