24V RO Solenoid Valve

24V RO Solenoid Valve

  • 24V RO Solenoid Valve
  • 24V RO Solenoid Valve
24V RO Solenoid Valve
Product Details:
Place of Origin: Ningbo, China
Brand Name: Brando
Certification: CE, ISO9001
Model Number: BPV01
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Inner box, then loaded into carton, then packed by pallet for sea shipment
Delivery Time: 7 working days after receive payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200000pcs per month
Contact Now
Detailed Product Description
Product Name: RO Solenoid Valve Operation: Direct Acting
Orifice Size: 1 To 5mm Port Size: 1/8'', 1/4'', 3/8''
Connection: Push In Fast Fit, Female Thread Body Material: PP, POM
Medium: Water, Air, Oil Working Pressure: 0 To 120psi
Seal Material: NBR, FKM, EPDM Voltage: 12VDC, 24VDC, 36VDC, 48VDC
High Light:

RO Solenoid Valve 24V

,

RO Water Purifier Solenoid Valve

,

Domestic RO Solenoid Valve

RO Solenoid Valve



Normally, solenoid valves for RO water purifiers (reverse osmosis systems) are of 2/2 way (1 inlet, 1 outlet of the open/closed type), ideal for water ON/OFF control. This RO solenoid valve uses a plunger to open and close an orifice, which either prevents or allows the flow of a medium. This plunger opens and closes by moving up and down by the use of an electromagnetic field generated by a magnet. As it does not use a membrane, the flow is restricted according to the orifice size. Normally this is between 1mm to 5mm. As the type of valves is direct acting, they do not depend on system pressure differences to function. This makes them ideal for the low flow, small, medium and high-pressure systems up to 120 psi. Port sizes range from 1/8'' to 3/8''.



Water purification systems can help to eliminate contaminants that can make you sick or affect the taste or feel of your water supply.In a Reverse Osmosis (RO) water purifying system, reverse osmosis is utilized to dissolve inorganic solids (such as salts) and removes them from a solution (such as water). This is achieved by using the household water pressure to push tap water through a semi permeable membrane. The membrane (which is about as thick as cellophane) allows only the water to pass through, not the impurities or contaminates. These impurities and contaminates are flushed down the drain. These systems use a lot of water, but they do remove all microbes that cause disease and a lot of chemicals. This is an extremely effective system for purifying water.



Dimension & Data of RO Solenoid Valves:

24V RO Solenoid Valve 0

Model
BPV01
Medium
Water, Air, Oil, etc
Medium Temperature Range
-10 to +80℃
Body Material
PP, POM
Working Pressure Range
0-120psi
Conection Type
Female Thread
Port Size
1/4'' NPT
Voltage
12VDC, 24VDC, 36VDC, 48VDC
Seal Material
NBR, FKM, EPDM



24V RO Solenoid Valve 1

Model
BPV02
Medium
Water, Air, Oil, etc
Medium Temperature Range
-10 to +80℃
Body Material
PP, POM
Working Pressure Range
0-120psi
Conection Type
Fast Fitting,
Tube OD 6.35mm
Voltage
12VDC, 24VDC, 36VDC, 48VDC
Seal Material
NBR, FKM, EPDM



Applications for RO Solenoid Valves:
1. Point of Use (POU) Drinking Water Systems
2. Home RO Systems
3. Commercial RO Systems
4. Point of Entry (POE) Water Filtration Systems
5. Office
6. Institutions
7. Lab
8. Water Purification
9. Ice Makers
10. Beverage Dispensing
11. Vending
12. R.V.
